Top ASTM A312 TP304, TP316, TP321, TP347 Stainless Pipes Supplier in China
ASTM A312 TP304, TP316, TP321, and TP347 stainless pipes deliver exceptional performance in high-temperature and corrosive environments. Available in seamless and welded variants, these pipes meet ASTM A312/ASME SA312 standards, ensuring durability and reliability for demanding industrial applications, including petrochemical and chemical processing, heat exchangers, and power generation systems.
Home - Products - Stainless Steel Welded Pipe - ASTM A312 TP304, TP316, TP321, TP347 Stainless Pipes
Specification Chart for Stainless Steel Pipes
This table provides essential insights into stainless steel pipe properties, offering engineers and industries a reliable reference for selecting durable, high-performance materials tailored to demanding operational and environmental challenges.
| Grade | Chemical Composition | Mechanical Properties | Size Range | Schedules | Wall Thickness | End Types | Applications |
|---|---|---|---|---|---|---|---|
| TP304 | C: ≤ 0.08%, Mn: ≤ 2.00%, P: ≤ 0.045%, S: ≤ 0.03%, Si: ≤ 1.00%, Cr: 18.0–20.0%, Ni: 8.0–11.0% | Tensile Strength: ≥ 515 MPa, Yield Strength: ≥ 205 MPa, Elongation: ≥ 35% | 1/8” to 24” (10.3mm to 610mm) | 10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH | 1mm to 60mm | Plain End, Beveled End, Threaded | High-temperature and corrosive environments, petrochemical, power generation |
| TP316 | C: ≤ 0.08%, Mn: ≤ 2.00%, P: ≤ 0.045%, S: ≤ 0.03%, Si: ≤ 1.00%, Cr: 16.0–18.0%, Ni: 10.0–14.0%, Mo: 2.00–3.00% | Tensile Strength: ≥ 515 MPa, Yield Strength: ≥ 205 MPa, Elongation: ≥ 35% | 1/8” to 24” (10.3mm to 610mm) | 10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH | 1mm to 60mm | Plain End, Beveled End, Threaded | High-temperature and corrosive environments, petrochemical, power generation |
| TP321 | C: ≤ 0.08%, Mn: ≤ 2.00%, P: ≤ 0.045%, S: ≤ 0.03%, Si: ≤ 1.00%, Cr: 17.0–19.0%, Ni: 9.0–12.0%, Ti: 5 × (C+N) min, 0.70 max | Tensile Strength: ≥ 515 MPa, Yield Strength: ≥ 205 MPa, Elongation: ≥ 35% | 1/8” to 24” (10.3mm to 610mm) | 10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH | 1mm to 60mm | Plain End, Beveled End, Threaded | High-temperature and corrosive environments, petrochemical, power generation |
| TP347 | C: ≤ 0.08%, Mn: ≤ 2.00%, P: ≤ 0.045%, S: ≤ 0.03%, Si: ≤ 1.00%, Cr: 17.0–19.0%, Ni: 9.0–13.0% | Tensile Strength: ≥ 515 MPa, Yield Strength: ≥ 205 MPa, Elongation: ≥ 35% | 1/8” to 24” (10.3mm to 610mm) | 10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH | 1mm to 60mm | Plain End, Beveled End, Threaded | High-temperature and corrosive environments, petrochemical, power generation |
